SR 900 Meber

BAND SAWS
FLYWHEEL DIAMETER 500/600/700/800/900

Produced to last over time and to reduce maintenace to minimum:

Brush to remove dust and encrustations
Double intake to ensure optimum sawdust exhaust and to guarantee a healthy work environment
Flywheel seals with easily interchangeable long-life hytrel rings (ø 500-600-700).

Maximum operating confort and absolute safety according to current standards:

Complete protection of sawblade and all moving parts
Electric installations certified to ISO 9000 – EN 29000 standards
Machines already tested as to noise level and sawdust emission according to European standards

DOWNLOAD DEPLIANT

Category: Wood

Description

Description

BAND SAWS

TECHNICAL DATA

Flywheel diameter mm.	500 20′	600 24″	700 28″	800 32″	900 36″	900 SUPER 36″
Working table sizes	580 x 630	580 x 800	694 x 1010	810 x 1145	810 x 1205	810 x 1205
Cutting capacity height x width mm.	280 x 475	345 x 585	430 x 680	420 x 780	450 x 840	550 x 840
Width of flywheel mm.	35	35	40	40	50	50
Flywheel R.P.M.	720	715	782	704	700	700
Lenght of blade, mm	3970	4400	5170	5480	6230	6580
Motor power HP	2	3	4	5,5	7,5	10
Net weight of machine Kg.	250	310	470	635	780	850
Noise level	80,5	79,8	82	83,5	89,1	94,8

Disegno

E	635	635	760	855	855	855
A	1860	2060	2320	2500	2760	2960
B	900	1060	1300	1400	1650	1650
C	855	875	920	970	1005	1005
D	100	100	100	100	140	140
